Data Structures- Space and Time Complexity
Observing the time complexity of different algorithms
- Space and Time Complexity
- Constant O(1)
- Linear O(n)
- Quadratic O(n^2)
- Logarithmic O(logn)
- Exponential O(2^n)
- Hacks
Space and Time Complexity
Space complexity refers to the amount of memory used by an algorithm to complete its execution, as a function of the size of the input. The space complexity of an algorithm can be affected by various factors such as the size of the input data, the data structures used in the algorithm, the number and size of temporary variables, and the recursion depth. Time complexity refers to the amount of time required by an algorithm to run as the input size grows. It is usually measured in terms of the "Big O" notation, which describes the upper bound of an algorithm's time complexity.
Why do you think a programmer should care about space and time complexity?
- Space and time complexity can help the program run in optimal conditions. Too much memory can cause the computer to crash and it will expensive to the user or the programmer if they have to upgrade their storage every single time. Users would also like to have a program that runs quickly, so programmers have to care about time complexity to make the user experience better. Space and time complexity can also help the programmer decide what they need to fix in their program and what they should strive for.
Take a look at our lassen volcano example from the data compression tech talk. The first code block is the original image. In the second code block, change the baseWidth to rescale the image.
from IPython.display import Image, display
from pathlib import Path
# prepares a series of images
def image_data(path=Path("images/"), images=None): # path of static images is defaulted
for image in images:
# File to open
image['filename'] = path / image['file'] # file with path
return images
def image_display(images):
for image in images:
display(Image(filename=image['filename']))
if __name__ == "__main__":
lassen_volcano = image_data(images=[{'source': "Peter Carolin", 'label': "Lassen Volcano", 'file': "lassen-volcano.jpg"}])
image_display(lassen_volcano)
from IPython.display import HTML, display
from pathlib import Path
from PIL import Image as pilImage
from io import BytesIO
import base64
# prepares a series of images
def image_data(path=Path("images/"), images=None): # path of static images is defaulted
for image in images:
# File to open
image['filename'] = path / image['file'] # file with path
return images
def scale_image(img):
#baseWidth = 625
#baseWidth = 1250
baseWidth = 2500
#baseWidth = 5000 # see the effect of doubling or halfing the baseWidth
#baseWidth = 10000
#baseWidth = 20000
#baseWidth = 40000
scalePercent = (baseWidth/float(img.size[0]))
scaleHeight = int((float(img.size[1])*float(scalePercent)))
scale = (baseWidth, scaleHeight)
return img.resize(scale)
def image_to_base64(img, format):
with BytesIO() as buffer:
img.save(buffer, format)
return base64.b64encode(buffer.getvalue()).decode()
def image_management(image): # path of static images is defaulted
# Image open return PIL image object
img = pilImage.open(image['filename'])
# Python Image Library operations
image['format'] = img.format
image['mode'] = img.mode
image['size'] = img.size
image['width'], image['height'] = img.size
image['pixels'] = image['width'] * image['height']
# Scale the Image
img = scale_image(img)
image['pil'] = img
image['scaled_size'] = img.size
image['scaled_width'], image['scaled_height'] = img.size
image['scaled_pixels'] = image['scaled_width'] * image['scaled_height']
# Scaled HTML
if __name__ == "__main__":
# Use numpy to concatenate two arrays
images = image_data(images = [{'source': "Peter Carolin", 'label': "Lassen Volcano", 'file': "lassen-volcano.jpg"}])
# Display meta data, scaled view, and grey scale for each image
for image in images:
image_management(image)
print("---- meta data -----")
print(image['label'])
print(image['source'])
print(image['format'])
print(image['mode'])
print("Original size: ", image['size'], " pixels: ", f"{image['pixels']:,}")
print("Scaled size: ", image['scaled_size'], " pixels: ", f"{image['scaled_pixels']:,}")
print("-- original image --")
display(HTML(image['html']))
Do you think this is a time complexity or space complexity or both problem?
- It is a both problem but space complexity is ultimately more of a problem. Because the larger the image, the more space and memory it takes up, space complexity is more of a problem. Space complexity is the cause of the time complexity, because the program takes longer to run the bigger the image is.
numbers = list(range(1000))
print(numbers)
print(numbers[263])
ncaa_bb_ranks = {1:"Alabama",2:"Houston", 3:"Purdue", 4:"Kansas"}
#look up a value in a dictionary given a key
print(ncaa_bb_ranks[1])
Space
This function takes two number inputs and returns their sum. The function does not create any additional data structures or variables that are dependent on the input size, so its space complexity is constant, or O(1). Regardless of how large the input numbers are, the function will always require the same amount of memory to execute.
def sum(a, b):
return a + b
print(sum(90,88))
print(sum(.9,.88))
Time
An example of a linear time algorithm is traversing a list or an array. When the size of the list or array increases, the time taken to traverse it also increases linearly with the size. Hence, the time complexity of this operation is O(n), where n is the size of the list or array being traversed.
for i in numbers:
print(i)
Space
This function takes a list of elements arr as input and returns a new list with the elements in reverse order. The function creates a new list reversed_arr of the same size as arr to store the reversed elements. The size of reversed_arr depends on the size of the input arr, so the space complexity of this function is O(n). As the input size increases, the amount of memory required to execute the function also increases linearly.
def reverse_list(arr):
n = len(arr)
reversed_arr = [None] * n #create a list of None based on the length or arr
for i in range(n):
reversed_arr[n-i-1] = arr[i] #stores the value at the index of arr to the value at the index of reversed_arr starting at the beginning for arr and end for reversed_arr
return reversed_arr
print(numbers)
print(reverse_list(numbers))
Time
An example of a quadratic time algorithm is nested loops. When there are two nested loops that both iterate over the same collection, the time taken to complete the algorithm grows quadratically with the size of the collection. Hence, the time complexity of this operation is O(n^2), where n is the size of the collection being iterated over.
for i in numbers:
for j in numbers:
print(i,j)
Space
This function takes two matrices matrix1 and matrix2 as input and returns their product as a new matrix. The function creates a new matrix result with dimensions m by n to store the product of the input matrices. The size of result depends on the size of the input matrices, so the space complexity of this function is O(n^2). As the size of the input matrices increases, the amount of memory required to execute the function also increases quadratically.
def multiply_matrices(matrix1, matrix2):
m = len(matrix1)
n = len(matrix2[0])
result = [[0] * n] * m #this creates the new matrix based on the size of matrix 1 and 2
for i in range(m):
for j in range(n):
for k in range(len(matrix2)):
result[i][j] += matrix1[i][k] * matrix2[k][j]
return result
print(multiply_matrices([[1,2],[3,4]], [[3,4],[1,2]]))
Time
An example of a log time algorithm is binary search. Binary search is an algorithm that searches for a specific element in a sorted list by repeatedly dividing the search interval in half. As a result, the time taken to complete the search grows logarithmically with the size of the list. Hence, the time complexity of this operation is O(log n), where n is the size of the list being searched.
def binary_search(arr, low, high, target):
while low <= high:
mid = (low + high) // 2 #integer division
if arr[mid] == target:
return mid
elif arr[mid] < target:
low = mid + 1
else:
high = mid - 1
target = 263
result = binary_search(numbers, 0, len(numbers) - 1, target)
print(result)
Space
The same algorithm above has a O(logn) space complexity. The function takes an array arr, its lower and upper bounds low and high, and a target value target. The function searches for target within the bounds of arr by recursively dividing the search space in half until the target is found or the search space is empty. The function does not create any new data structures that depend on the size of arr. Instead, the function uses the call stack to keep track of the recursive calls. Since the maximum depth of the recursive calls is O(logn), where n is the size of arr, the space complexity of this function is O(logn). As the size of arr increases, the amount of memory required to execute the function grows logarithmically.
Time
An example of an O(2^n) algorithm is the recursive implementation of the Fibonacci sequence. The Fibonacci sequence is a series of numbers where each number is the sum of the two preceding ones, starting from 0 and 1. The recursive implementation of the Fibonacci sequence calculates each number by recursively calling itself with the two preceding numbers until it reaches the base case (i.e., the first or second number in the sequence). The algorithm takes O(2^n) time in the worst case because it has to calculate each number in the sequence by making two recursive calls.
def fibonacci(n):
if n <= 1:
return n
else:
return fibonacci(n-1) + fibonacci(n-2)
#print(fibonacci(5))
#print(fibonacci(10))
#print(fibonacci(20))
#print(fibonacci(30))
print(fibonacci(40))
Space
This function takes a set s as input and generates all possible subsets of s. The function does this by recursively generating the subsets of the set without the first element, and then adding the first element to each of those subsets to generate the subsets that include the first element. The function creates a new list for each recursive call that stores the subsets, and each element in the list is a new list that represents a subset. The number of subsets that can be generated from a set of size n is 2^n, so the space complexity of this function is O(2^n). As the size of the input set increases, the amount of memory required to execute the function grows exponentially.
def generate_subsets(s):
if not s:
return [[]]
subsets = generate_subsets(s[1:])
return [[s[0]] + subset for subset in subsets] + subsets
print(generate_subsets([1,2,3,4,5,6]))
#print(generate_subsets(numbers))
Using the time library, we are able to see the difference in time it takes to calculate the fibonacci function above.
- Based on what is known about the other time complexities, hypothesize the resulting elapsed time if the function is replaced.
import time
start_time = time.time()
print(fibonacci(34))
end_time = time.time()
total_time = end_time - start_time
print("Time taken:", total_time, "seconds")
start_time = time.time()
print(fibonacci(35))
end_time = time.time()
total_time = end_time - start_time
print("Time taken:", total_time, "seconds")
Hacks
- Record your findings when testing the time elapsed of the different algorithms.
- Although we will go more in depth later, time complexity is a key concept that relates to the different sorting algorithms. Do some basic research on the different types of sorting algorithms and their time complexity.
- Why is time and space complexity important when choosing an algorithm?
- Should you always use a constant time algorithm / Should you never use an exponential time algorithm? Explain?
- What are some general patterns that you noticed to determine each algorithm's time and space complexity?
Complete the Time and Space Complexity analysis questions linked below. Practice
Hacks solved
Findings
- The time elapsed for Constant algorithms - O(1) - is constant. The time and space complexity is always the same no matter what.
- The time elapsed for Linear algorithms - O(N) - changes at a constant rate as the size of the file/list/array increases. The increase is constant, so it is linear not exponential. As the size increases, the amount of memory required also increases at a constant rate.
- The time elapsed for Quadratic algorithm - O(N^2) - increases at a quadratic rate as the size increases. Instead of increasing at a constant rate, it increases by either double, triple, quadruple, etc.
- The time elapsed for Logarithmic algorithms - O(logn) - decreases at an exponential rate as the size increases. Like binary search, the time divides by half each time.
- The time elapsed for Exponential algorithms - O(2^N) - increasea at an exponential rate as the size increases. Like recursions, the time increases exponentially.
Research
- Selection Sort - O(N^2)
- Merge Sort - O(log(N))
- Count Sort - O(N+K)
- Quick Sort - O(log(N))
- Heap Sort - O(log(N))
- Tree Sort - O(log(N))
Importance
Time and space complexity is important because it can determine the user's experience. It will also determine how well the algorithm will work and hoe well the program will work as intended. If the algorithm takes too long, then the program will not run and may even crash the program. If certain algorithms require too much memory and "space", then the program will also not run and may crash. Therefore, time and space complextiy must be taken into account when choosing an algorithm.
Constant vs Exponential
Constant time algorithms are generally much better than exponenial algorithms. Even when the list/array/file is not that big, the exponential algorithm will take much longer than the constant algorithm. However, if the list or file is small, then it may be better for exponential algorithms to be used because it can be quicker than constant algorithms.
General Patterns
No matter the algorithm, the bigger the list, array, or file traversed, the longer the time and memory it takes for the program to run. Some algorithms just take significantly less time, but they all increase. What the algorithm does also changes how long it takes. Binary search, for example, cuts down the list by half every single time, which is why it is much faster than exponential algorithms. Algorithms that have to iterate through the list, and sometimes more than once, causes it to take so much time.
Practice Problems
- What is the time, and space complexity of the following code:
import random
a = 0
b = 0
for i in range(N):
a = a + random()
for i in range(M):
b= b + random()
Options:
- O(N * M) time, O(1) space
- O(N + M) time, O(N + M) space
- O(N + M) time, O(1) space
- O(N * M) time, O(N + M) space
Answer: 3. O(N + M) time, O(1) space
- What is the time complexity of the following code:
a = 0
for i in range(N):
for j in reversed(range(i,N)):
a = a + i + j
Options:
- O(N)
- O(N*log(N))
- O(N * Sqrt(N))
- O(N*N)
Answer: 4. O(N*N)
- What is the time complexity of the following code:
k = 0
for i in range(n//2,n):
for j in range(2,n,pow(2,j)):
k = k + n / 2
Options:
- O(n)
- O(N log N)
- O(n^2)
- O(n^2Logn)
Answer: 2. O(N log N)
- What does it mean when we say that an algorithm X is asymptotically more efficient than Y?
Options:
- X will always be a better choice for small inputs
- X will always be a better choice for large inputs
- Y will always be a better choice for small inputs
- X will always be a better choice for all inputs
Answer: 2. X will always be a better choice for large inputs
- What is the time complexity of the following code:
a = 0
i = N
while (i > 0):
a += i
i //= 2
Options:
- O(N)
- O(Sqrt(N))
- O(N / 2)
- O(log N)
Answer: 4. O(log N)
- Which of the following best describes the useful criterion for comparing the efficiency of algorithms?
Options:
- Time
- Memory
- Both of the above
- None of the above
Answer: 3. Both of the above
- How is time complexity measured?
Options:
- By counting the number of algorithms in an algorithm.
- By counting the number of primitive operations performed by the algorithm on a given input size.
- By counting the size of data input to the algorithm.
- None of the above
Answer: 2. By counting the number of primitive operations performed by the algorithm on a given input size
- What will be the time complexity of the following code?
for i in range(n):
i=i*k
Options:
- O(n)
- O(k)
- O(logkn)
- O(lognk)
Answer:
-
O(logkn)
-
What will be the time complexity of the following code?
value = 0
for i in range(n):
for j in range(i):
value=value+1
Options:
- n
- (n+1)
- n(n-1)
- n(n+1)
Answer: 3. n(n-1)
- Algorithm A and B have a worst-case running time of O(n) and O(logn), respectively. Therefore, algorithm B always runs faster than algorithm A.
Options:
- True
- False
Answer: 2. False
